Large Temp. Difference Heat Exchange Absorption Unit
Adopting large Delta T heat exchange technology can significantly improve the transfer capacity of existing pipeline by increasing the Delta T between the supply/return water of the primary network. General speaking, it is a kind of high-efficiency heat exchanger based on LiBr absorption heat pump, with functions that traditional heat exchangers are not equipped with. It makes full use of the thermal potential energy of high-temperature hot water in the primary network and greatly improves the utilization rate of energy.
-
Direct Fired Absorption Chiller
Direct fired LiBr absorption chiller (heater) is a type of refrigeration (heating) equipment powered by natural gas, coal gas, biogas, fuel oil etc. LiBr aqueous solution is used as the circulating working fluid, in which the LiBr solution is used as the absorbent and water is the refrigerant. The chiller primarily comprises of the HTG, LTG, condenser, evaporator, absorber, high-temp heat exchanger, low-temp heat exchanger, auto purge device, burner, vacuum pump and canned pumps.
Attached below is the latest brochure of this product and our company profile.
-
Natural Gas Absorption Chiller
Natural Gas LiBr absorption chiller (heater) is a type of refrigeration (heating) equipment powered by natural gas, coal gas, biogas, fuel oil etc. LiBr aqueous solution is used as the circulating working fluid, in which the LiBr solution is used as the absorbent and water is the refrigerant. The chiller primarily comprises of the HTG, LTG, condenser, evaporator, absorber, high-temp heat exchanger, low-temp heat exchanger, auto purge device, burner, vacuum pump and canned pumps.
Attached below is the latest brochure of this product and our company profile.
-
Vapor Absorption Chiller
Vapor fire LiBr absorption chiller is a type of refrigeration equipment powered by vapor heat, in which the LiBr solution is used as the absorbent and water is the refrigerant. Unit is main composed of the HTG, LTG, condenser, evaporator, absorber, high temperature HX, low temp. HX, condensate water HX, auto purge device, vacuum pump, canned pump, etc.
Attached below is the latest brochure of this product and our company profile.
-
Solar Absorption Chiller
The solar absorption chiller is a device that utilizes solar energy as the primary source to achieve cooling through the chemical reaction between LiBr and water. Solar collectors convert solar energy into thermal energy, which is used to heat the solution in the generator, causing the separation of LiBr and water. The water vapor enters the condenser, where it is cooled and then moves to the evaporator to absorb heat for cooling. Subsequently, it is absorbed by the LiBr absorbent, completing the cooling cycle. The solar lithium bromide absorption chiller is characterized by its environmental friendliness and energy efficiency, making it widely used in areas with abundant sunlight and cooling needs. It is a highly efficient and sustainable cooling solution.
-
Fully Premixed Extra Low NOx Vacuum Water Boiler
“Fully Premixed Extra Low NOx Vacuum Water Boiler” utilizes “Hope Deepblue Micro Flame Low Temperature Combustion Technology” to upgrade and iterate the “Vacuum Water Boiler”, which reduces the product and operating costs and improves the efficiency of the unit under the premise of ensuring safety.
-
Utral Low NOx Vacuum Hot Water Boiler
Hope Deepblue has successfully developed a condensate low NOx vacuum hot water boiler, whose efficiency can reach 104%. Condensate vacuum hot water boiler adds a Exhaust condenser on standard vacuum hot water boiler to recycle the sensible heat from exhaust gas and the latent heat from water vapour, so it can reduce the Exhaust emission temperature and recycle the heat to heat the circulating water of boiler, improving efficiency of boiler evidently.
-
Direct Fired Absorption Chiller
Direct fired LiBr absorption chiller (heater) is a type of refrigeration (heating) equipment powered by natural gas, coal gas, biogas, fuel oil etc. LiBr aqueous solution is used as the circulating working fluid, in which the LiBr solution is used as the absorbent and water is the refrigerant.
The chiller primarily comprises of the HTG, LTG, condenser, evaporator, absorber, high-temp heat exchanger, low-temp heat exchanger, auto purge device, burner, vacuum pump and canned pumps.Attached below is the latest brochure of this product and our company profile.
-
Steam LiBr Absorption Chiller
Steam fire LiBr absorption chiller is a type of refrigeration equipment powered by steam heat, in which the LiBr solution is used as the absorbent and water is the refrigerant. Unit is main composed of the HTG, LTG, condenser, evaporator, absorber, high temperature HX, low temp. HX, condensate water HX, auto purge device, vacuum pump, canned pump, etc.
Attached below is the latest brochure of this product and our company profile.
-
Multi Energy LiBr Absorption Chiller
Multi Energy LiBr Absorption Chiller is a type of refrigeration equipment driven by several energy, like solar energy, exhaust/flue gas, steam and hot water, in which the LiBr solution is used as the absorbent and water is the refrigerant. Unit is main composed of the HTG, LTG, condenser, evaporator, absorber, high temperature HX, low temp. HX, condensate water HX, auto purge device, vacuum pump, canned pump, etc.
Attached below is the latest our company profile.
-
LiBr Absorption Heat Pump
LiBr Absorption Heat Pump is a heat-powered device, which recycles and transfers LT (Low Temperature) waste heat to HT (High Temperature) heat sources for the purpose of process heating or district heating. It can be classified into Class I and Class II, depending on circulation method and operation status.
Attached below is the latest brochure of this product and our company profile.
-
Low Temp. Absorption Chiller
Working principle
Liquid evaporation is a phase changing and heat absorption process. The lower pressure, the lower evaporation.
for example, under one atmosphere pressure, the evaporation temperature of water is 100°C, and at 0.00891 atmosphere pressure, the evaporation temperature of water will drop to 5°C. If a low-pressure environment can be established and water is used as the evaporation medium, low-temperature water with a saturation temperature corresponding to the current pressure can be obtained. If the liquid water can be continuously supplied, and the low pressure can be maintained stably, the low-temperature water of the required temperature can be continuously provided.
LiBr absorption chiller, depending on the characteristics of LiBr solution, takes the heat of steam, gas, hot water and other media as the driving source, and realizes the evaporation, absorption, condensation of refrigerant water and the generation process of solution in the vacuum equipment cycle, so that the low-temperature evaporation process of refrigerant water can continue. That means the function of continuously providing low temperature chilled water driven by the heat source can be realized.Attached below is the latest our company profile.
